Mircom MIX-M500S

Supervised Output Module

Condition: New
Brand: Mircom
Status: Obsolete
SKU: 80845
Manufacturer Part #: MIX-M500S
Replacement: MIX-M500SAP

Description

The MIX-M500S Supervised Control Module provides supervised monitoring of wiring to load devices that require an external power supply to operate, such as horns, strobes, or bells. It is capable of Styles Y and Z supervision. Upon command from the control panel, the MIX-M500S will disconnect the supervision and connect the external power supply across the load device. The disconnection of the supervision provides a positive indication to the panel that the control relay actually turned on. The external power supply is always relay isolated from the communication loop, so that a trouble condition on the power supply will never interfere with the rest of the system. Full analog measurement of the supervised wiring is transmitted back to the panel and can be used to detect impedance changes or other special test functions.

Additional information

Weight 0.5 lbs
Dimensions 4.25 × 4.65 × 1.10 in
Brand

Condition

New

Production Status

Obsolete

Resources

Intelligent Addressable Modules; MIX-500 Series
Mircom – Data Sheet
