Potter PFC-4410RC


4-Zone Conventional Releasing Control Panel

Availability: Please Call for Availability

  • Factory New
Brand: Potter FireAlarm.com Part #: 45329 Categories: , Manufacturer Part #: PFC-4410RCSecondary Part #: 3006142


The Potter Model PFC-4410RC is a flexible multi-hazard releasing control panel that is well suited for a number of applications. The PFC-4410RC is listed for use with pre-action and deluge sprinkler suppression systems and agent based fire suppression systems.

The panel utilizes a microprocessor-based system that has 24 Standard Programs, which covers a majority of installations. The simple to follow Menu Structure programs the entire system in a matter of minutes. In addition to the Standard Programs, the panel allows custom programming to accommodate any installation.

The panel is Tenth Edition UL listed, ULC listed, Factory Mutual, California State Fire Marshal (CSFM), New York Materials Equipment Acceptance (MEA) Approved, CE Marked, and RoHS Compliant. The PFC-4410RC is housed in a durable steel cabinet with removable door and key lock. The panel is available in either a red or white finish and an optional flush mount trim ring is available. The cabinet contains knockouts on the side, back and top of the cabinet to ease installation. In addition, the cabinet will house up to 18 amp-hour batteries that will provide in excess of 90 hours of standby power.


Weight 16 lbs
Dimensions 18.25 × 14.50 × 4.75 in

Potter Electric Signal Company, LLC





Unit of Measurement

EA (Each)


Control Panel




Multi-Hazard Releasing

Production Status



  • Multi-Hazard Operation
  • Four Class B Initiating Circuits
  • Two Class B Supervisory Circuits **
  • Four Class B Output Circuits
  • Programmable Cross Zoning
  • Supervised Microprocessor
  • 32 Character Alpha-Numeric LCD Display
  • Custom Banner Message and Zone Description text
  • Custom Zone Description Text
  • On Board Menu Driven Programming Controls
  • Releasing Circuits Protected From False Activation
  • Continuous or Timed Discharge
  • 40 Event History Buffer
  • Walktest with Automatic Time-out
  • Alarm, Trouble Supervisory, and Waterflow relays
  • Optional Class A Initiating Zone and output module
  • 34 character LED supplemental display
  • 24 Standard Programs in Panel Memory
  • Password Protection for all Programming
  • 24 Hour Clock
  • Suitable for agent or water-based extinguishing
  • Programmable pre-discharge timers*
  • One Class B Abort circuit* (Defaults to additional supervisory zone in water based mode.)
  • Four Abort modes*

* Available in Chemical mode only

** One zone programmable as abort in chemical mode.


Potter - Technical Data

PFC-4410RC Releasing Panel for Water and Agent Extinguishing Systems

Potter - Installation Manual

PFC-4410RC Releasing Panel for Water and Agent Extinguishing Systems

Potter - Compatibility Document

Notification Compatibility Document

Potter - Compatibility Document
