Bosch Security FMM-7045

Multiplex manual station, single, red
The single‐action manual station is UL listed and meets Americans with Disabilities Act (ADA) requirements. An address on the polling circuit is easily set with rotary switches. The pull-down handle locks in the activated position. It is reset by opening the unit with a key and then relocking it.

Availability: Please call for availability
Condition: New
Brand: Bosch Security
Status: Discontinued
SKU: 50634
Manufacturer Part #: FMM-7045
Note: This item has been discontinued by the manufacturer with no suggested replacement.

Get Your Perfect Pull Station

Shop Custom Pull Stations

Description

The FMM‐7045 MUX manual stations are UL Listed fire alarm initiating devices. They can be connected along with other multiplex (MUX) devices on the FPE-7039, D7039, DS9431 MUX expansion modules. The FPE-7039 or D7039 are used with the FPD‐7024 or D7024 FACPs. The DS9431 is used with the DS9400 FACPs. The FACPs supervise the entire MUX loop, including the manual stations, for troubles, alarms, and ground fault conditions. Each manual station occupies only one address on the MUX bus. A manual station can be addressed for any point within the MUX module’s 9 to 255 range. A manual station is generally installed near building exits, allowing persons evacuating the building to activate the fire alarm. They have optional scored acrylic break rods and a pull handle that locks in the activated position. These features allow easy identification of alarm activation points. The manual stations have a low profile and rounded edges to fit most design applications. They are manufactured in conformance with the standards set forth in the Americans with Disabilities Act (ADA). All components are painted or have plated surfaces to inhibit corrosion. Non-corroding screw terminals are provided for wire connections.

Documents

Description

The FMM‐7045 MUX manual stations are UL Listed fire alarm initiating devices. They can be connected along with other multiplex (MUX) devices on the FPE-7039, D7039, DS9431 MUX expansion modules. The FPE-7039 or D7039 are used with the FPD‐7024 or D7024 FACPs. The DS9431 is used with the DS9400 FACPs. The FACPs supervise the entire MUX loop, including the manual stations, for troubles, alarms, and ground fault conditions. Each manual station occupies only one address on the MUX bus. A manual station can be addressed for any point within the MUX module’s 9 to 255 range.

A manual station is generally installed near building exits, allowing persons evacuating the building to activate the fire alarm. They have optional scored acrylic break rods and a pull handle that locks in the activated position. These features allow easy identification of alarm activation points.

The manual stations have a low profile and rounded edges to fit most design applications. They are manufactured in conformance with the standards set forth in the Americans with Disabilities Act (ADA). All components are painted or have plated surfaces to inhibit corrosion. Non-corroding screw terminals are provided for wire connections.

Additional information

Weight 1.34 lbs
Dimensions 3.25 × 3.75 × 4.75 in
Color

Red

Construction

Die-Cast Metal

Programming

Rotary Dials

Material Qualities

Corrosion Resistant

Mounting

Flush, Surface

Operation

Break-Glass, Key Reset, Single-Action

Terminal Type

Screw Terminals

Condition

New

Brand

Production Status

Discontinued

Reviews

There are no reviews yet.

Be the first to review “Bosch Security FMM-7045”

Attributes

Weight 1.34 lbs
Dimensions 3.25 × 3.75 × 4.75 in
Color

Red

Construction

Die-Cast Metal

Programming

Rotary Dials

Material Qualities

Corrosion Resistant

Mounting

Flush, Surface

Operation

Break-Glass, Key Reset, Single-Action

Terminal Type

Screw Terminals

Condition

New

Brand

Production Status

Discontinued

Product Features

  • Easy addressing with rotary switches
  • Terminal connections and low current draw
  • Key-lock reset
  • Replaceable scored acrylic break rod option
  • UL Listed and ADA compliant
