Johnson Controls IFC-320


Control Panel Fire Alarm Intelligent Addressable

Availability: Estimated 6 Weeks

Condition: New
Brand: Johnson Controls
Status: Active
SKU: 71653
Manufacturer Part #: IFC-320


In stand-alone or network configurations, the IFC-320 meet virtually every application requirement. Designed with modularity and ease of system planning, the IFC320 can be configured with just a few devices for small building applications, or for a large campus or high-rise application. Simply add additional peripheral equipment to suit the application. For Canadian applications with IFC-320C, an optional ACM Series annunciator can be mounted in the same cabinet (up to 48 zones/points, order seperately). The FireWatch Series intenet monitoring modules IPDACT2 and IPDACT-2UD permit monitoring of alarm signals over the Internet, saving the monthly cost of two dedicated business telephone lines. Although not required, the secondary telephone line may be retained providing backup communication over the public switched telephone line.

Additional information

Weight 16 lbs

Johnson Controls





Control Panel






Production Status




  • Listed to UL Standard 864, 9th edition.
  • One isolated intelligent Signaling Line Circuit (SLC) Style 4, 6 or 7.
  • Up to 159 detectors (any mix of ion, photo, thermal, or multisensor) and 159 modules (Addressable pull stations, normally open contact devices, two-wire smoke, notification, or relay). 318 devices maximum.
  • Standard 80-character display.
  • Network options:

– High-speed network for up to 200 nodes (IFC2-3030, IFC2-640, IFC-320(C), JNCA-2, JDVC, IFI, IFW, IFC-3030, IFC640, and JNCA).

– Standard network or up to 103 nodes (IFC-640, IFC2-640, IFC-320, IFC-3030, IFC2-3030, IFC-200, IFC-300/400, IFC-1010, IFC-2020, JDVC-EM, IFI, IFW, JNCA or JNCA-2 Network Annunciators). Up to 54 nodes when DVC is used in network paging.

  • 6.0 amp power supply with four Class A/B built-in Notification Appliance Circuits (NAC). Selectable System Sensor, Wheelock, or Gentex strobe synchronization.
  • Built-in Alarm, Trouble, Security, and Supervisory relays.
  • VeriFire® Tools online or offline programming utility. Upload/Download, save, store, check, compare, and simulate panel databases. Upgrade panel firmware.
  • Autoprogramming and Walk Test reports.
  • Optional universal 318-point DACT.
  • 80-character remote annunciators (up to 32).
  • EIA-485 annunciators, including custom graphics.
  • Printer interface (80-column and 40-column printers).
  • History file with 800-event capacity in nonvolatile memory, plus separate 200-event alarm-only file.
  • Alarm Verification selection per point, with tally.
  • Autoprogramming and Walk Test reports.
  • Presignal/Positive Alarm Sequence (PAS).
  • Silence inhibit and Auto Silence timer options.
  • NAC coding functions:

– March time.

– Temporal.

– California two-stage coding.

– Canadian two-stage.

– Strobe synchronization.

  • Field-programmable on panel or on PC, with VeriFire Tools program check, compare, simulate.
  • Full QWERTY keypad.
  • Battery charger supports 18 – 200 amp hour batteries
  • Non-alarm points for lower priority functions.
  • Remote ACK/Signal Silence/System Reset/Drill via monitor modules.
  • Automatic time control functions, with holiday exceptions.
  • Surface Mount Technology (SMT) electronics.
  • Extensive, built-in transient protection.
  • Powerful Boolean logic equations.


Intelligent Addressable Fire Alarm System; IFC-320(E)(C)
Johnson Controls – Data Sheet
