FirePrint Smoke Detector, Photo Thermal Sensing
The Siemens FP-11 is an intelligent, plug-in, two-wire addressable FirePrint™ detector designed for use with Siemens FireFinder® XLS and MXL® fire alarm control panels. It combines photoelectric smoke sensing and thermal detection with advanced microprocessor-based FirePrint technology to distinguish real fire conditions from deceptive phenomena such as cigarette smoke.
Using Application Specific Detection (ASD), the FP-11 can be programmed from the control panel to match defined hazard profiles (e.g., office, healthcare, parking garage, air duct, warehouse). Detector sensitivity, pre-alarm levels, and environmental compensation are panel-controlled, optimizing response while minimizing nuisance alarms.
The detector includes a dust-resistant, field-cleanable chamber, multicolor LED status indication, and remote testing/programming capability using the Siemens DPU or FPI-32 programmer/tester.
The Siemens FP-11 is an intelligent, plug-in, two-wire addressable FirePrint™ detector designed for use with Siemens FireFinder® XLS and MXL® fire alarm control panels. It combines photoelectric smoke sensing and thermal detection with advanced microprocessor-based FirePrint technology to distinguish real fire conditions from deceptive phenomena such as cigarette smoke.
Using Application Specific Detection (ASD), the FP-11 can be programmed from the control panel to match defined hazard profiles (e.g., office, healthcare, parking garage, air duct, warehouse). Detector sensitivity, pre-alarm levels, and environmental compensation are panel-controlled, optimizing response while minimizing nuisance alarms.
The detector includes a dust-resistant, field-cleanable chamber, multicolor LED status indication, and remote testing/programming capability using the Siemens DPU or FPI-32 programmer/tester.
| Weight | 0.3 lbs |
|---|---|
| Dimensions | 2.00 × 4.00 × 4.00 in |
| Manufacturer | Siemens Industry, Inc. |
| Brand | Siemens |
| Condition | New |
| Unit of Measurement | EA (Each) |
| Production Status | Discontinued |
| Type | Multi-Criteria Detector |
| Style | Plug-In |
| Detectable Medium | Heat, Smoke |
| Compatibility | |
| Programming | DPU, FPI-32 |
| Detection Method | Fixed Temperature, Photoelectric |
| Thermal Rating | 135°F |
| Operating Temperature | 32°F (0°C) to 100°F (38°C) |
| Voltage | 16 − 27 VDC |
| Listings & Approvals | CSFM, FM, NYC Fire Dept, UL, ULC |
Only logged in customers who have purchased this product may leave a review.
| Weight | 0.3 lbs |
|---|---|
| Dimensions | 2.00 × 4.00 × 4.00 in |
| Manufacturer | Siemens Industry, Inc. |
| Brand | Siemens |
| Condition | New |
| Unit of Measurement | EA (Each) |
| Production Status | Discontinued |
| Type | Multi-Criteria Detector |
| Style | Plug-In |
| Detectable Medium | Heat, Smoke |
| Compatibility | |
| Programming | DPU, FPI-32 |
| Detection Method | Fixed Temperature, Photoelectric |
| Thermal Rating | 135°F |
| Operating Temperature | 32°F (0°C) to 100°F (38°C) |
| Voltage | 16 − 27 VDC |
| Listings & Approvals | CSFM, FM, NYC Fire Dept, UL, ULC |
